Aniline Blue

Protocol List







Aniline Blue C.I. 42780 (ws 42755)



Properties

UV-VIS range: 594-610

Appearance: Purple-Brown Powder

Dye Class: Aminotriarylmethane



Biological Applications: Widely used as a counter stain, collagen stain, connective tissue stain, and in bacteriological media.



Commercial Applications: Limited use as an indicator, formerly used as a basic dye in textiles.



Note:  Aniline Blue is a mixture of water soluble Acid Blue 22 (CI 42755) and Acid Blue 93 (CI 42780)







Gomoris 1-step Trichrome Stain





Preparation of Stain Solutions



Trichrome Stain

    Chromotrope 2R 0.6gm, Aniline Blue 0.3gm,

    Glacial Acetic Acid 1.0 ml, Phosphotungstic acid 0.8gm,

    distilled water 100 ml.



Fixation : 10%NBF



Staining Procedure

  1. Deparafinize sections through xylene.
  2. Hydrate tissues through graded ethanol.
  3. Rinse sections in distilled water.
  4. Place in Bouin's solution (at 58 degrees C) for 10 minutes.
  5. Rinse in running water until the yellow fades from the sections.
  6. Place sections in Weigert's iron hematoxylin solution for 5 minutes. (see Acid Fuchsin Van Gieson Stain)
  7. Rinse sections in running tap water for 10 minutes.
  8. Place sections in Trichrome stain for 15 minutes.
  9. Place in 0.5% acetic acid water 2 minutes, 2 changes.
  10. Deydrate in graded alcohols..
  11. Clear through xylene and mount with a synthetic resin medium.Results  Muscle Fibers - red, Collagen - blue, Nuclei - blue/black, Erythrocytes - red.

Mallory's Connective Tissue Stain



 Preparation of Stain Solutions

0.5 % Acid Fuchsin

    0.5 gm of Acid Fuchsin in 100 ml distilled water

Aniline Blue Solution

    0.5 gm Aniline Blue, 2 gm Orange G, 1gm phosphotungstic acid, dissolve in 100 ml distilled water.



Fixation: Zenker

 Staining Procedure

1.      Deparafinize sections through xylene.

2.      Hydrate tissues through graded ethanol.

3.      Rinse sections in distilled water.

4.    Dezenkerize if sections are Zenker fixed (10 minutes iodine, 10 minutes hypo solution).

5.    Rinse in distilled water.

6.    Stain sections in Acid Fuchsin solution for 1-5minutes depending on intensity of stain desired.

7.    Wipe off excess dye from slides and immerse slides in the Aniline Blue solution for 20minutes to 1 hour.

8.    Transfer to 95% ethanol, several changes to remove excess dye.

9.    Dehydrate clear and mount with a synthetic resin.



Results



Collagenous fibers - blue

Nuclei - red

neuroglia fibers - red

myelin - yellow

ground substances of cartilage, bone, mucus, amyloid - blue









REFERENCES:

Lillie, R.D. 1977. H.J. Conn's Biological Stains, 9th edition.  Williams & Wilkins, Baltimore.  pp. 289-291.

Churukian, Charles J. 2000, Manual of the Special Stains Laboratory, 5th edition. University of Rochester, Rochester. pp. 79-80.

Gomori, G.: A rapid one-step trichrome stain.  American Journal of Clinical Pathology. 20: 661-664,1950.

Green, F.J. 1990. The Sigma-Aldrich Handbook of Stains, Dyes and Indicators. Aldrich Chemical Comnpany, Milwaukee. pp.96-97.

Clark, G. 1981. Staining Procedures, 4rth edition.  Williams & Wilkins, Baltimore. pp.117.
